Explosion Proof Lamp
Short Description:
Advantages：
·EXDexplosionproofstandard;
·Reliablestructure:3 individualchamberforPSU,cable,
lightsource;
·SuitableforexplosivegasenvironmentI/A,IIBand IlC,
temperaturerangeT1-T6;
·Applicalions:chemical workshop,minw, oil field,ect.
Advantages：
·EXDexplosionproofstandard;
·Reliablestructure:3 individualchamberforPSU,cable,
lightsource;
·SuitableforexplosivegasenvironmentI/A,IIBand IlC,
temperaturerangeT1-T6;
·Applicalions:chemical workshop,minw, oil field,ect.
PHOTOELECTRIC PARAMETER：
Item No. Power consumption CCT CRI Luminous flux Luminous efficacy
EXD100 100W 2200~ 6500K 70~80ra 9000lm 90~100lm/w
EXD150 150W 2200~ 6500K 70~80ra 13500lm 90~100lm/w
EXD200 200W 2200~ 6500K 70~80ra 18000lm 90~100lm/w
Optical Materials
・Distribution : Narrow, Medium, Wide ・Housing : Die cast aluminum
・Housing : Die cast aluminum ・Lens : Glass
・Lens : Glass ・Bracket : 304 stainless steel
・Bracket : 304 stainless steel ・Finish color : Black
・Finish color : Black
Remark
・Beam angle (half intensity) : 90°, 120°
・Lumen maintenance(L70) : 50,000hours at
25°C
Electrical Remark
・Built-in power supply: Explosive-proof SMPS ・Operation Temperature range : -40～+40°C
・Input voltage : AC90 ~ 305V ・IP code : IP66
・Power factor : > 0.9 at full load ・Certification : CE, CCC, CQC, KCC
・Surge protection : 10kV (Line-Ground) ・Standard : Ex d II T3/T4/T6 Gb
LIGHT DISTRIBUTIONCURVE
DIMENSIONSDRAWING
PACKAGEINFORMATION
| Item | Length | Width | Height | N.W. | G.W. |
| Exd100 | 365mm | 365mm | 275mm | 8.5kg | 10kg |
| Exd150 | 365mm | 365mm | 275mm | 8.5kg | 10kg |
| Exd200 | 365mm | 365mm | 275mm | 8.5kg | 10kg |
Standard finish of H.S.Perforated Cable Tray as below, customize available:
| Suffix | Finish | Suffix | Finish | Suffix | Finish |
| G | Pre -galvanized/PG/GI | P | Powder coated | Z | Zinc plated |
| H | Hot dip galvanized/HDG | A | Alumnium | E | Electrolytic polishing |
| S4 | Stainless steel SS04 | FRP | Fiber reinforced plstic/GRP | M | Mill/Plain steel |
| S6 | Stainless steel SS06 | F | Fire rated |
