High Mast Lights
Short Description:
Advantages:
・Delicate distribution: small KCOB light source with
high-effetive aluminum reflector, precise B.A suitable for
various high mast lighting application;
・Maintainance free: built-in inventronics driver, top quality;
・Housing: made of die casting aluminum with heatpipe,
IP66 and anti-corrosion protection;
・HPS color: provide 2000~2200K CCT option, same as
sodium lamp;
・Smart control system compatible;
Advantages
・Delicate distribution: small KCOB light source with
high-effetive aluminum reflector, precise B.A suitable for
various high mast lighting application;
・Maintainance free: built-in inventronics driver, top quality;
・Housing: made of die casting aluminum with heatpipe,
IP66 and anti-corrosion protection;
・HPS color: provide 2000~2200K CCT option, same as
sodium lamp;
・Smart control system compatible;
Light Source:
K-COB is a unique LED packaging pattern –
by using exclusive laser ceramic to replace
traditional silicone and phosphor,
this brand new generation LED light source brings
better reliability and extremly low lumen decay.
Photoelectric Parameter:
| ltem No. | Power consumption | CCT | CRI | Luminous flux | Luminous efficacy |
| HM200 | 200W | 2200~6500K | 70~85ra | 23000lm | 105~125lm/w |
| HM300 | 300W | 2200~6500K | 70~85ra | 34500lm | 105~125Im/w |
| HM400 | 400W | 2200~6500K | 70~85ra | 46000lm | 105~125lm/w |
| HM500 | 500W | 2200~6500K | 70~85ra | 57500lm | 105~125lm/w |
Optical Materials
・Distribution: Narrow, Medium, Wide ・Housing: Die cast aluminum
・Beam angle (half intensity): 10° , 15°, 30°，60° ・Reflector: Aluminum
・Lumen maintenance (L70): 50,000 hours at 25℃ ・Lamp housing: Cathode electrophoretic, treatment&coating
・Finish color: Black
・Heat sink: Heat pipe(copper)
Electrical Remark
・Built-in power supply: Moso/ Inventronics/Meanwell ・Operation temperature range: -40～+30°C
・Input voltage: AC90 ~ 305V ・IP code: IP66
・Power factor: > 0.9 at full load ・Certification: CE, KCC, CCC, CQC,PSE
・Surge protection: 10kV (Line-Ground)
Light Distribution Curve
Dimension Drawing
Package Information
| Item | Length | Width | Height | N.W. | G.W. |
| HM300 | 415mm | 392mm | 350mm | 7.6kg | 9.8kg |
| HM400 | 605mm | 467mm | 350mm | 8.6kg | 11.5kg |
| HM500 | 605mm | 467mm | 350mm | 11.5kg | 14.5kg |
Standard finish of H.S.Perforated Cable Tray as below, customize available:
| Suffix | Finish | Suffix | Finish | Suffix | Finish |
| G | Pre -galvanized/PG/GI | P | Powder coated | Z | Zinc plated |
| H | Hot dip galvanized/HDG | A | Alumnium | E | Electrolytic polishing |
| S4 | Stainless steel SS04 | FRP | Fiber reinforced plstic/GRP | M | Mill/Plain steel |
| S6 | Stainless steel SS06 | F | Fire rated |
